Parts:

AC Adapter

Small hook, flat head, convex mouth, concave tip, extended rod, large hook, Y hook

Ｉ-1      Ｉ-2      Ｉ-3   Ｉ-4      Ｉ-5     Ｉ-6      Ｉ-7         I-8

（A-1） （A-2）  （A-3） （A-4） （A-5） （A-6）

Note: series I is made of iron, and series A is made of aluminum.50N and below recommended series A, 100n-1000n recommended I.The hook and y-hook are only used for 1000N testing.

USES:

1. Simple determination of tension spring, rubber and other forces.

2. Operation force measurement of switch buttons: telephone, computer and remote control.

3. The insertion and extraction forces of the connector can be tested simultaneously.

4. Grasp the peak cracking force of new materials such as glass, carbon, ceramics and plastics.

5. Bending force measurement of thin plate, round bar, wood, etc.

6. Stripping test: stripping force of adhesive tape, PCB, adhesive tape, etc.

7. Elongation test: tensile test of new rubber materials.

8. Hardness test: test of anchorage, fruit, lipstick and viscosity.

9. Easy to open and pull cans, etc.

10. Tensile strength test: tensile strength and riveting strength test of terminals.

11. Breaking test: tensile breaking test of wire, copper wire, etc.

12. Touch power test of switch contact: touch power test of mechanical contact

Features:

1. Man-machine engineering design.With antiskid rubber handle and strong metal case,

The sensor can withstand 200% overload.The product is reliable and durable.

2. The liquid crystal screen can display measurement data and units upside down.

3. Real-time tracking test and two peak modes are available.

4. Measurement units (K)N, Kgf (gf), Lbf (ozf) are available.

5. Programmable high/low value color LED indicator and output to indicate passing/failing the test.

6. The instrument can store 1000 data.

7. The computer can be connected with RS232C or USB interface.Can process 1000 data per second and generate analysis chart based on statistics.

8. Range overload and battery low voltage indicator.

Technical parameters：

規格：

外觀尺寸：
